X3D Model Documentation: TestJsonEncoding.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
  3  <X3D profile='Immersive' version='3.3'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.3.xsd'>
  4       <head>
  5            <component level='1' name='CADGeometry'/>
  6            <component level='1' name='H-Anim'/>
  7            <unit category='length' conversionFactor='0.9144' name='Yards'/>
  8            <unit category='angle' conversionFactor='0.0174532925167' name='Degrees'/>
  9            <meta name='title' content='TestJsonEncoding.x3d'/>
 10            <meta name='creator' content='Don Brutzman'/>
 11            <meta name='created' content='29 March 2015'/>
 12            <meta name='modified' content='20 October 2019'/>
 13            <meta name='description' content='Test scene to ensure that X3dToJson xslt stylesheet translator properly converts X3D source into JavaScript Object Notation (JSON).'/>
 14            <meta name='reference' content='TestJsonEncoding.json'/>
 15            <meta name='reference' content='https://www.web3d.org/wiki/index.php/X3D_JSON_Encoding'/>
 16            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Basic/development/TestJsonEncoding.x3d'/>
 17            <meta name='reference' content='https://www.web3d.org/x3d/stylesheets/X3dToJson.xslt'/>
 18            <meta name='reference' content='https://www.web3d.org/x3d/stylesheets/X3dToJson.html'/>
 19            <meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
 20            <meta name='license' content='../license.html'/>
 21       </head>
<!--
<!-- -->

<!-- to top Index for DEF nodes: ImageCloudlessEarth, MaterialLightBlue, TextMessage, ViewUpClose

Index for Viewpoint node: ViewUpClose
-->
 22       <Scene>
 23            <!-- excerpted from HelloWorld.x3d -->
 24            <WorldInfo title='TestJsonEncoding.x3d'/>
 25            <Group>
 26                 <Viewpoint DEF='ViewUpClose' centerOfRotation='0 -1 0' description='Hello world!' position='0 -1 7'/>
 27                 <Transform rotation='0 1 0 3'>
 28                      <Shape>
 29                           <Sphere/>
 30                           <Appearance>
 31                                <!-- Test leading zeroes inserted before (and trailing zeroes inserted after) decimal points: diffuseColor='.1 0.5 1.' -->
 32
                              <!-- Material MaterialLightBlue is a DEF node that has 1 USE node: USE_1 -->
                               <Material DEF='MaterialLightBlue' diffuseColor='.1 0.5 1.'/>
 33                                <ImageTexture DEF='ImageCloudlessEarth'   url=' "earth-topo.png " "earth-topo.jpg " "earth-topo-small.gif " "https://www.web3d.org/x3d/content/examples/Basic/earth-topo.png " "https://www.web3d.org/x3d/content/examples/Basic/earth-topo.jpg " "https://www.web3d.org/x3d/content/examples/Basic/earth-topo-small.gif " '/>
 34                           </Appearance>
 35                      </Shape>
 36                 </Transform>
 37                 <Transform translation='-.1 -2 -.2'>
 38                      <!-- Test leading zeroes inserted between -. values: translation='-.1 -2 -.2' -->
 39                      <Shape>
 40                           <Text DEF='TextMessage' string='"Hello" "JSON!"'>
 41                                <FontStyle justify='"MIDDLE" "MIDDLE"'/>
 42                           </Text>
 43                           <Appearance>
 44                                <Material USE='MaterialLightBlue'/>
 45                           </Appearance>
 46                      </Shape>
 47                 </Transform>
 48            </Group>
 49       </Scene>
 50  </X3D>
<!--
<!-- -->

<!-- to top Index for DEF nodes: ImageCloudlessEarth, MaterialLightBlue, TextMessage, ViewUpClose

Index for Viewpoint node: ViewUpClose
-->
X3D Tooltips element index: Appearance, component, FontStyle, Group, head, ImageTexture, Material, meta, Scene, Shape, Sphere, Text, Transform, unit, Viewpoint, WorldInfo, X3D, accessType and type, XML data types, field types
-->
