X3D Model Documentation: A4_GeoLocation.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
  3  <X3D profile='Immersive' version='3.3'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.3.xsd'>
  4       <head>
  5            <component level='1' name='Geospatial'/>
  6            <meta name='title' content='A4_GeoLocation.x3d'/>
  7            <meta name='creator' content='Martin Reddy SRI, original example'/>
  8            <meta name='creator' content='Don Brutzman NPS, X3D encoding'/>
  9            <meta name='created' content='26 June 2000'/>
 10            <meta name='modified' content='20 October 2019'/>
 11            <meta name='description' content='Specification example georeferencing VRML objects: display standard VRML cone at latitude/longitude location of Lossiemouth, Scotland.'/>
 12            <meta name='reference' content='http://www.geovrml.org/1.0/doc/examples.html'/>
 13            <meta name='reference' content='originals/geoloc.wrl'/>
 14            <meta name='reference' content='VRML 97 encoding http://www.geovrml.org/1.0/doc/examples/geoinline.wrl'/>
 15            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Basic/Geospatial/A4_GeoLocation.x3d'/>
 16            <meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
 17            <meta name='license' content='../license.html'/>
 18       </head>
 19       <Scene>
 20            <WorldInfo title='A4_GeoLocation.x3d'/>
 21            <Group>
 22                 <Background groundColor='0 0 0' skyColor='1 1 1'/>
 23                 <GeoViewpoint description='Initial GeoViewpoint' orientation='1 0 0 -1.57' position='51.5122 -40.0 10000000' containerField='children'/>
 24                 <Shape>
 25                      <Appearance>
 26                           <Material diffuseColor='0.8 1.0 0.3'/>
 27                           <ImageTexture   url=' "images/earth.gif " "images/earth.jpg " "images/earth2.gif " "images/earth3.jpg " "https://www.web3d.org/x3d/content/examples/Basic/Geospatial/images/earth.gif " "https://www.web3d.org/x3d/content/examples/Basic/Geospatial/images/earth.jpg " "https://www.web3d.org/x3d/content/examples/Basic/Geospatial/images/earth2.gif " "https://www.web3d.org/x3d/content/examples/Basic/Geospatial/images/earth3.jpg " '/>
 28                      </Appearance>
 29                      <GeoElevationGrid creaseAngle='1.05' geoGridOrigin='-90 -180 0' xDimension='11' xSpacing='36' zDimension='11' zSpacing='18' height='0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0'/>
 30                 </Shape>
 31                 <GeoLocation geoCoords='57.7174 -3.286119 200000' containerField='children'>
 32                      <Transform rotation='1 0 0 3.1415926'>
 33                           <Shape>
 34                                <Appearance>
 35                                     <Material diffuseColor='1 1 0'/>
 36                                </Appearance>
 37                                <Cone bottomRadius='100000' height='500000'/>
 38                           </Shape>
 39                      </Transform>
 40                 </GeoLocation>
 41            </Group>
 42       </Scene>
 43  </X3D>

X3D Tooltips element index: Appearance, Background, component, Cone, GeoElevationGrid, GeoLocation, GeoViewpoint, Group, head, ImageTexture, Material, meta, Scene, Shape, Transform, WorldInfo, X3D, accessType and type, XML data types, field types
-->
