X3D Model Documentation: HelloWorldEncryptionResult_Decrypted8JAN2023.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.2//EN" "https://www.web3d.org/specifications/x3d-3.2.dtd">
  3  <X3D profile='Immersive' version='3.2 xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.2.xsd'>
  4       <head>
  5            <meta name='titlecontent='HelloWorldEncryptionResult_Decrypted8JAN2023.x3d'/>
  6            <meta name='descriptioncontent='Decryption of simple X3D example for XML encryption for security, originally encrypted 14 years earlier! Actual encrypted document is in XML file HelloWorldEncryptionResult.xml, this test still worked after fourteen years following an upgrade to X3D-Edit to version 4.0 !'/>
  7            <meta name='referencecontent='HelloWorldEncryptionResult.xml'/>
  8            <meta name='createdcontent='2 July 2008'/>
  9            <meta name='modifiedcontent='9 January 2023'/>
 10            <meta name='creatorcontent='Don Brutzman, Mike Bailey'/>
 11            <meta name='infocontent='default attribute values removed after decryption'/>
 12            <meta name='referencecontent='X3dSecurityReadMe.html'/>
 13            <meta name='referencecontent='keystore/SelectSigningSecretKey.png'/>
 14            <meta name='referencecontent='keystore/SecretKey_key.b64'/>
 15            <meta name='referencecontent='https://www.web3d.org/x3d/content/examples/HelloWorld.x3d'/>
 16            <meta name='referencecontent='https://www.web3d.org/x3d/content/examples/Basic/Security/HelloWorldEncryptionInput.x3d'/>
 17            <meta name='referencecontent='https://www.web3d.org/x3d/content/examples/Basic/Security/HelloWorldEncryptionResult.xml'/>
 18            <meta name='referencecontent='https://www.web3d.org/x3d/content/examples/Basic/Security/HelloWorldDecrypted.x3d'/>
 19            <meta name='identifiercontent='https://www.web3d.org/x3d/content/examples/Basic/Security/HelloWorldEncryptionResult_Decrypted8JAN2023.x3d'/>
 20            <meta name='generatorcontent='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
 21            <meta name='subjectcontent='X3D security, XML encryption, secret key'/>
 22            <meta name='licensecontent='../license.html'/>
 23       </head>
<!--

<!-- to top Index for DEF node: Index for Viewpoint node: Viewpoint_1
-->
 24       <Scene>
 25            <!-- Example scene to illustrate X3D tags and attributes. -->
 26            <WorldInfo title='HelloWorldEncryptionResult_Decrypted8JAN2023.x3d'/>
 27            <Group>
 28                 <Viewpoint centerOfRotation='0 -1 0description='Hello world!position='0 -1 7'/>
 29                 <Transform rotation='0 1 0 3'>
 30                      <Shape>
 31                           <Sphere/>
 32                           <Appearance>
 33                                <Material diffuseColor='0 0.5 1'/>
 34                                <ImageTexture   url=' "../earth-topo.png " "../earth-topo.jpg " "../earth-topo-small.gif " "https://www.web3d.org/x3d/content/examples/Basic/earth-topo.png " "https://www.web3d.org/x3d/content/examples/Basic/earth-topo.jpg " "https://www.web3d.org/x3d/content/examples/Basic/earth-topo-small.gif " '/>
 35                           </Appearance>
 36                      </Shape>
 37                 </Transform>
 38                 <Transform translation='0 -2 0'>
 39                      <Shape>
 40                           <Text string='"Hello" "world!"'>
 41                                <FontStyle justify='"MIDDLE" "MIDDLE"'/>
 42                           </Text>
 43                           <Appearance>
 44                                <Material diffuseColor='0.1 0.5 1'/>
 45                           </Appearance>
 46                      </Shape>
 47                 </Transform>
 48            </Group>
 49       </Scene>
 50  </X3D>
<!--
