X3D Model Documentation: Example15.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
  3  <X3D profile='Immersive' version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
  4       <head>
  5            <meta name='title' content=' Example15.x3d '/>
  6            <meta name='translator' content='Don Brutzman'/>
  7            <meta name='created' content='26 June 2000'/>
  8            <meta name='modified' content='2 January 2025'/>
  9            <meta name='creator' content='X3D working group'/>
 10            <meta name='description' content='VRML 97 specification example: Robot. Seek or zoom in towards the robot to start a simple animation sequence.'/>
 11            <meta name='reference' content='originals/exampleD_15.wrl'/>
 12            <meta name='specificationSection' content='VRML 97, ISO/IEC 14772-1, Part 1: Functional specification and UTF-8 encoding, D.15 Robot'/>
 13            <meta name='specificationUrl' content='https://www.web3d.org/documents/specifications/14772/V2.0/part1/examples.html#D.15'/>
 14            <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Basic/Vrml97Specification/Example15.x3d '/>
 15            <meta name='generator' content='X3D-Edit 3.3, https://www.web3d.org/x3d/tools/X3D-Edit'/>
 16            <meta name='license' content='../license.html'/>
 17       </head>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->
<!-- to top DEF nodes index: A, Arm, Near, WALK

Index for Viewpoint node: Viewpoint_1

Index for ExternProtoDeclare definitions: Pendulum, Shuttle
-->
 18       <Scene>
 19            <WorldInfo title='Example15.x3d'/>
 20            <ExternProtoDeclare name='Shuttle'   url=' "Example14.x3d#Shuttle" "https://www.web3d.org/x3d/content/examples/Basic/Vrml97Specification/Example14.x3d#Shuttle" "Example14.wrl#Shuttle" "https://www.web3d.org/x3d/content/examples/Basic/Vrml97Specification/Example14.wrl#Shuttle" '>
 21                 <field name='rate' type='SFTime' accessType='initializeOnly'/>
 22                 <field name='distance' type='SFFloat' accessType='initializeOnly'/>
 23                 <field name='children' type='MFNode' accessType='initializeOnly'/>
 24                 <field name='startTime' type='SFTime' accessType='inputOutput'/>
 25                 <field name='stopTime' type='SFTime' accessType='inputOutput'/>
 26                 <field name='loop' type='SFBool' accessType='initializeOnly'/>
 27            </ExternProtoDeclare>
 28            <ExternProtoDeclare name='Pendulum'   url=' "Example14.x3d#Pendulum" "https://www.web3d.org/x3d/content/examples/Basic/Vrml97Specification/Example14.x3d#Pendulum" "Example14.wrl#Pendulum" "https://www.web3d.org/x3d/content/examples/Basic/Vrml97Specification/Example14.wrl#Pendulum" '>
 29                 <field name='rate' type='SFTime' accessType='initializeOnly'/>
 30                 <field name='maxAngle' type='SFFloat' accessType='initializeOnly'/>
 31                 <field name='children' type='MFNode' accessType='initializeOnly'/>
 32                 <field name='startTime' type='SFTime' accessType='inputOutput'/>
 33                 <field name='stopTime' type='SFTime' accessType='inputOutput'/>
 34                 <field name='loop' type='SFBool' accessType='initializeOnly'/>
 35            </ExternProtoDeclare>
 36            <NavigationInfo speed='20' type='"WALK" "ANY"'/>
 37            <Viewpoint description='zoom in' position='0 0 150'/>
 38
          <!-- ROUTE information for Near node:  [from enterTime to WALK.startTime ] [from enterTime to Arm.startTime ] [from exitTime to WALK.stopTime ] [from exitTime to Arm.stopTime ] -->
           <ProximitySensor DEF='Near' size='200 200 200'/>
 39
          <!-- ROUTE information for WALK node:  [from Near.enterTime to startTime ] [from Near.exitTime to stopTime ] -->
           <ProtoInstance name='Shuttle' DEF='WALK'>
 40                 <fieldValue name='stopTime' value='1'/>
 41                 <fieldValue name='rate' value='10'/>
 42                 <fieldValue name='distance' value='20'/>
 43                 <fieldValue name='children'>
 44                      <Transform rotation='0 1 0 1.57'>
 45                           <Shape>
 46
                              <!-- Appearance A is a DEF node that has 2 USE nodes: USE_1, USE_2 -->
                               <Appearance DEF='A'>
 47                                     <Material diffuseColor='0 0.5 0.7'/>
 48                                </Appearance>
 49                                <!-- head -->
 50                                <Box/>
 51                           </Shape>
 52                           <Transform scale='1 5 1' translation='0 -5 0'>
 53                                <Shape>
 54                                     <Appearance USE='A'/>
 55                                     <!-- body -->
 56                                     <Sphere/>
 57                                </Shape>
 58                           </Transform>
 59                           <Transform rotation='0 1 0 1.57' translation='1.5 0 0'>
 60
                              <!-- ProtoInstance Arm is a DEF node that has 1 USE node: USE_1
                              <!-- ROUTE information for Arm node:  [from Near.enterTime to startTime ] [from Near.exitTime to stopTime ] -->
                               <ProtoInstance name='Pendulum' DEF='Arm'>
 61                                     <fieldValue name='stopTime' value='1'/>
 62                                     <fieldValue name='rate' value='1'/>
 63                                     <fieldValue name='maxAngle' value='0.52'/>
 64                                     <fieldValue name='children'>
 65                                          <Transform translation='0 -3 0'>
 66                                               <Shape>
 67                                                    <Appearance USE='A'/>
 68                                                    <Cylinder height='4' radius='0.5'/>
 69                                               </Shape>
 70                                          </Transform>
 71                                     </fieldValue>
 72                                </ProtoInstance>
 73                           </Transform>
 74                           <Transform rotation='0 -1 0 1.57' translation='-1.5 0 0'>
 75                                <ProtoInstance USE='Arm'/>
 76                           </Transform>
 77                      </Transform>
 78                 </fieldValue>
 79            </ProtoInstance>
 80            < ROUTE  fromNode='Near' fromField='enterTime' toNode='WALK' toField='startTime'/>
 81            < ROUTE  fromNode='Near' fromField='enterTime' toNode='Arm' toField='startTime'/>
 82            < ROUTE  fromNode='Near' fromField='exitTime' toNode='WALK' toField='stopTime'/>
 83            < ROUTE  fromNode='Near' fromField='exitTime' toNode='Arm' toField='stopTime'/>
 84       </Scene>
 85  </X3D>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->
<!-- to top DEF nodes index: A, Arm, Near, WALK

Index for Viewpoint node: Viewpoint_1

Index for ExternProtoDeclare definitions: Pendulum, Shuttle
-->
X3D Tooltips element index: Appearance, Box, Cylinder, ExternProtoDeclare, field, fieldValue, head, Material, meta, NavigationInfo, ProtoInstance, ProximitySensor, ROUTE, Scene, Shape, Sphere, Transform, Viewpoint, WorldInfo, X3D, plus documentation for accessType definitions, type definitions, XML data types, and field types

Event Graph ROUTE Table entries with 4 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

Near
ProximitySensor
enterTime
SFTime
→
ROUTE
event to
(1)
WALK
ProtoInstance
startTime
SFTime
Near
ProximitySensor
enterTime
SFTime
→
ROUTE
event to
(1)
Arm
ProtoInstance
startTime
SFTime
Near
ProximitySensor
exitTime
SFTime
→
ROUTE
event to
(1)
WALK
ProtoInstance
stopTime
SFTime
Near
ProximitySensor
exitTime
SFTime
→
ROUTE
event to
(1)
Arm
ProtoInstance
stopTime
SFTime

      Arm
ProtoInstance
Pendulum 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declaration with
direct access to other nodes, and thus has potential to produce run-time animation.

      WALK
ProtoInstance
Shuttle 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declaration with
direct access to other nodes, and thus has potential to produce run-time animation.

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀
-->
