X3D Model Documentation: ExtrusionHeart.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
  3  <X3D profile='Immersive' version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
  4       <head>
  5            <meta name='title' content='ExtrusionHeart.x3d'/>
  6            <meta name='description' content='Simple extrusion of a Valentine heart.'/>
  7            <meta name='creator' content='Class participants in course Introduction to VRML/X3D.'/>
  8            <meta name='created' content='14 February 2001'/>
  9            <meta name='modified' content='20 October 2019'/>
 10            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Basic/course/ExtrusionHeart.x3d'/>
 11            <meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
 12            <meta name='license' content='../license.html'/>
 13       </head>
<!--
<!-- to top Index for DEF node: Index for Viewpoint node: Viewpoint_1
-->
 14       <Scene>
 15            <WorldInfo title='ExtrusionHeart.x3d'/>
 16            <Viewpoint description='Extrusion Heart' orientation='1 0 0 1.57' position='0 -4 0'/>
 17            <Transform translation='0 -0.5 0'>
 18                 <Shape>
 19                      <Extrusion creaseAngle='3.14159' crossSection='0 0.8 0.2 1 0.7 0.95 1 0.5 0.8 0 0.5 -0.3 0 -0.7 -0.5 -0.3 -0.8 0 -1 0.5 -0.7 0.95 -0.2 1 0 0.8' scale='0.01 0.01 0.8 0.8 1 1 0.8 0.8 0.01 0.01' solid='false' spine='0 0 0 0 0.1 0 0 0.5 0 0 0.9 0 0 1 0'/>
 20                      <Appearance>
 21                           <Material diffuseColor='0.8 0.3 0.3'/>
 22                      </Appearance>
 23                 </Shape>
 24            </Transform>
 25       </Scene>
 26  </X3D>
<!--
