X3D Model Documentation: X3dBookWebsiteLogo.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
  3  <X3D profile='Immersive' version='3.3'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.3.xsd'>
  4       <head>
  5            <meta name='title' content='X3dBookWebsiteLogo.x3d'/>
  6            <meta name='description' content='Extrusion of X3D book used for x3dGraphics.com website logo'/>
  7            <meta name='creator' content='Leonard Daly and Don Brutzman'/>
  8            <meta name='created' content='26 February 2007'/>
  9            <meta name='modified' content='20 October 2019'/>
 10            <meta name='reference' content='https://X3dGraphics.com'/>
 11            <meta name='reference' content='https://www.web3d.org/x3d/content/examples/X3dResources.html'/>
 12            <meta name='rights' content='Copyright Don Brutzman and Leonard Daly 2007'/>
 13            <meta name='subject' content='X3D book, X3D graphics, X3D-Edit, http://www.x3dGraphics.com'/>
 14            <meta name='Image' content='X3dBookLogo.jpg'/>
 15            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/Chapter06GeometryPointsLinesPolygons/X3dBookWebsiteLogo.x3d'/>
 16            <meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
 17            <meta name='license' content='../license.html'/>
 18       </head>
<!--
<!-- to top Index for DEF node: Index for Viewpoint nodes: Viewpoint_1, Viewpoint_2
-->
 19       <Scene>
 20            <WorldInfo title='X3dBookWebsiteLogo.x3d'/>
 21            <Background skyColor='.6 .8 1'/>
 22            <Viewpoint description='front view' orientation='1 0 0 -1.25' position='0 0.8 .6'/>
 23            <Viewpoint description='bottom view' position='0 0 2'/>
 24            <Transform>
 25                 <Shape>
 26                      <Extrusion ccw='false' creaseAngle='1' crossSection='0 .04 .028 .025 .05 0 .3 0 .25 .1 .07 .1 .035 .088 0 .06 -.035 .088 -.07 .1 -.25 .1 -.3 0 -.05 0 -.025 .028 0 .04' spine='0 0 .25 0 0 -.25'/>
 27                      <Appearance>
 28                           <Material diffuseColor='.8 .9 .8'/>
 29                           <ImageTexture repeatS='false' repeatT='false'   url=' "X3dImageRotated.png " "X3dImageRotated.gif " "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/Chapter06GeometryPointsLinesPolygons/X3dImageRotated.png " "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/Chapter06GeometryPointsLinesPolygons/X3dImageRotated.gif " '/>
 30                           <TextureTransform center='-.5 0' scale='2 1'/>
 31                           <!-- TODO restore image, use TextureTransform rotation instead -->
 32                      </Appearance>
 33                 </Shape>
 34            </Transform>
 35       </Scene>
 36  </X3D>
<!--
