X3D Model Documentation: Sky.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.2//EN" "https://www.web3d.org/specifications/x3d-3.2.dtd">
  3  <X3D profile='Immersive' version='3.2 xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.2.xsd'>
  4       <head>
  5            <meta name='titlecontent='Sky.x3d'/>
  6            <meta name='descriptioncontent='Sky overhead image'/>
  7            <meta name='creatorcontent='Herbert Stocker'/>
  8            <meta name='translatorcontent='Don Brutzman'/>
  9            <meta name='createdcontent='18 April 2006'/>
 10            <meta name='translatedcontent='3 December 2011'/>
 11            <meta name='modifiedcontent='20 October 2019'/>
 12            <meta name='referencecontent='originals/Sky.wrl'/>
 13            <meta name='referencecontent='Stocker_06_Followers.pdf'/>
 14            <meta name='referencecontent='http://www.hersto.com/Publications/Followers'/>
 15            <meta name='referencecontent='http://www.hersto.com/Publications/Followers/Sky.png'/>
 16            <meta name='referencecontent='http://www.hersto.com/Publications/Followers/Sky.wrl'/>
 17            <meta name='referencecontent='https://www.web3d.org/x3d/content/examples/X3dSceneAuthoringHints.html'/>
 18            <meta name='identifiercontent='https://www.web3d.org/x3d/content/examples/Basic/Followers/Sky.x3d'/>
 19            <meta name='generatorcontent='Vrml97ToX3dNist, http://ovrt.nist.gov/v2_x3d.html'/>
 20            <meta name='generatorcontent='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
 21            <meta name='licensecontent='../../license.html'/>
 22       </head>
<!--

<!--
Event Graph ROUTE Table shows event connections.
-->

<!-- to top Index for DEF nodes: Proxi, TrSky

Index for ProtoDeclare definition: Sky
-->
 23       <Scene>
 24            <WorldInfo title='Sky.x3d'/>
 25            <Background skyColor='0.8 0.2 0.4'/>
 26            <ProtoDeclare name='Sky'>
 27                 <ProtoBody>
 28                      <Group>
 29                           <ProximitySensor DEF='Proxisize='1.0E30 1.0E30 1.0E30'/>
 30                           <Transform DEF='TrSky'>
 31                                <Transform rotation='0.0 1.0 0.0 -1.5scale='300.0 200.0 300.0'>
 32                                     <Shape>
 33                                          <Appearance>
 34                                               <ImageTexture   url=' "Sky.png " "https://www.web3d.org/x3d/content/examples/Basic/Followers/Sky.png " '/>
 35                                          </Appearance>
 36                                          <IndexedFaceSet creaseAngle='4.0solid='falsecoordIndex='0 1 2 -1 0 2 3 -1 0 3 4 -1 0 4 5 -1 0 5 6 -1 0 6 7 -1 0 7 8 -1 0 8 9 -1 0 9 10 -1 0 10 1 -1 12 2 1 -1 1 11 12 -1 13 3 2 -1 2 12 13 -1 14 4 3 -1 3 13 14 -1 15 5 4 -1 4 14 15 -1 16 6 5 -1 5 15 16 -1 17 7 6 -1 6 16 17 -1 18 8 7 -1 7 17 18 -1 19 9 8 -1 8 18 19 -1 20 10 9 -1 9 19 20 -1 11 1 10 -1 10 20 11 -1 22 12 11 -1 11 21 22 -1 23 13 12 -1 12 22 23 -1 24 14 13 -1 13 23 24 -1 25 15 14 -1 14 24 25 -1 26 16 15 -1 15 25 26 -1 27 17 16 -1 16 26 27 -1 28 18 17 -1 17 27 28 -1 29 19 18 -1 18 28 29 -1 30 20 19 -1 19 29 30 -1 21 11 20 -1 20 30 21 -1'>
 37                                               <TextureCoordinate point='0.5 0.5 0.335 0.5 0.366 0.398 0.449 0.335 0.551 0.335 0.634 0.398 0.665 0.5 0.634 0.602 0.551 0.665 0.449 0.665 0.366 0.602 0.181 0.5 0.242 0.303 0.401 0.181 0.599 0.181 0.758 0.303 0.819 0.5 0.758 0.697 0.599 0.819 0.401 0.819 0.242 0.697 0.05 0.5 0.136 0.222 0.361 0.05 0.639 0.05 0.864 0.222 0.95 0.5 0.864 0.778 0.639 0.95 0.361 0.95 0.136 0.778'/>
 38                                               <Coordinate point='0.0 1.0 0.0 0.0 0.883 -0.367 -0.227 0.883 -0.297 -0.367 0.883 -0.114 -0.367 0.883 0.114 -0.227 0.883 0.297 0.0 0.883 0.367 0.227 0.883 0.297 0.367 0.883 0.115 0.367 0.883 -0.114 0.227 0.883 -0.297 0.0 0.542 -0.709 -0.438 0.542 -0.573 -0.709 0.542 -0.219 -0.709 0.542 0.219 -0.438 0.542 0.573 0.0 0.542 0.709 0.438 0.542 0.573 0.709 0.542 0.219 0.709 0.542 -0.219 0.438 0.542 -0.573 0.0 0.0 -1.0 -0.618 0.0 -0.809 -1.0 0.0 -0.309 -1.0 0.0 0.309 -0.618 0.0 0.809 0.0 0.0 1.0 0.618 0.0 0.809 1.0 0.0 0.309 1.0 0.0 -0.309 0.618 0.0 -0.809'/>
 39                                          </IndexedFaceSet>
 40                                     </Shape>
 41                                </Transform>
 42                           </Transform>
 43                      </Group>
 44                 </ProtoBody>
 45            </ProtoDeclare>
 46            <ProtoInstance name='Sky'/>
 47       </Scene>
 48  </X3D>
<!--

<!--
Event Graph ROUTE Table shows event connections.
-->

<!-- to top Index for DEF nodes: Proxi, TrSky

Index for ProtoDeclare definition: Sky
-->
X3D Tooltips element index: Appearance, Background, Coordinate, Group, head, ImageTexture, IndexedFaceSet, meta, ProtoBody, ProtoDeclare, ProtoInstance, ProximitySensor, Scene, Shape, TextureCoordinate, Transform, WorldInfo, X3D, accessType and type, XML data types, field types

Event Graph ROUTE Table with 0 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.


ProtoInstance
Sky
No ROUTE connection found for output events from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.
Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀

-->
