NurbsPatchSurfaceExampleWithOahuTexture.x3d (X3dToXhtml listing)

<Scene>

<Shape>

<Coordinate DEF='NC' containerField='controlPoint' point='-10 -10 0 -10 -5 0 -10 0 0 -10 5 0 -10 10 0 -5 -10 0 -5 -5 2.5 -5 0 5 -5 5 2.5 -5 10 0 0 -10 0 0 -5 2.5 0 0 5 0 5 2.5 0 10 0 5 -10 0 5 -5 2.5 5 0 15 5 5 2.5 5 10 0 10 -10 0 10 -5 0 10 0 0 10 5 0 10 10 0'/>

</NurbsPatchSurface>

<ImageTexture url=' "PearlHarborLowResolution.jpg

" "https://savage.nps.edu/Savage/Locations/Hawaii/PearlHarborLowResolution.jpg

" '/>

</Appearance>

</Shape>

</Transform>

<TimeSensor DEF='TS' cycleInterval='6' loop='true'/>

<CoordinateInterpolator DEF='CI' key='0 .5 1' keyValue='-10 -10 0 -10 -5 0 -10 0 0 -10 5 0 -10 10 0 -5 -10 0 -5 -5 2.5 -5 0 5 -5 5 2.5 -5 10 0 0 -10 0 0 -5 2.5 0 0 5 0 5 2.5 0 10 0 5 -10 0 5 -5 2.5 5 0 15 5 5 2.5 5 10 0 10 -10 0 10 -5 0 10 0 0 10 5 0 10 10 0 -10 -10 0 -10 -5 0 -10 0 0 -10 5 0 -10 10 0 -5 -10 0 -5 -5 0 -5 0 0 -5 5 0 -5 10 0 0 -10 0 0 -5 0 0 0 0 0 5 0 0 10 0 5 -10 0 5 -5 0 5 0 0 5 5 0 5 10 0 10 -10 0 10 -5 0 10 0 0 10 5 0 10 10 0 -10 -10 0 -10 -5 0 -10 0 0 -10 5 0 -10 10 0 -5 -10 0 -5 -5 2.5 -5 0 5 -5 5 2.5 -5 10 0 0 -10 0 0 -5 2.5 0 0 5 0 5 2.5 0 10 0 5 -10 0 5 -5 2.5 5 0 15 5 5 2.5 5 10 0 10 -10 0 10 -5 0 10 0 0 10 5 0 10 10 0'/>

< ROUTE fromNode='TS' fromField='fraction_changed' toNode='CI' toField='set_fraction'/>

< ROUTE fromNode='CI' fromField='value_changed' toNode='NC' toField='set_point'/>

</Scene>

</X3D>

Event Graph ROUTE Table with 2 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

TS
TimeSensor
fraction_changed
SFFloat

→
ROUTE
event to
(1)

CI
CoordinateInterpolator
set_fraction
SFFloat

then

CI
CoordinateInterpolator
value_changed
MFVec3f

→
ROUTE
event to
(2)

NC
Coordinate
set_point
MFVec3f

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀

1	`<?xml version="1.0" encoding="UTF-8"?>`
2	`<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">`
3	<X3D profile='Immersive' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
4	<head>
5	<component level='1' name='NURBS'/>
6	<meta name='title' content='NurbsPatchSurfaceExampleWithOahuTexture.x3d'/>
7	<meta name='description' content='ImageTexture applied to animated NURBS patch using NurbsPatchSurface. Compare regular animation rendering to wireframe-mode rendering (if supported by X3D/VRML browser) in order to observe dynamic tessellation.'/>
8	<meta name='creator' content='Jeffrey Weekley, Charles Adams'/>
9	<meta name='created' content='6 February 2003'/>
10	<meta name='modified' content='20 October 2019'/>
11	<meta name=' warning ' content=' missing default values for knot and weight array fields in NurbsPatchSurface (weight default: all 1 values) ; not required by X3D specification, but some browsers may fail without them. '/>
12	<meta name=' warning ' content=' under development, needs to be upgraded to final version of X3D NURBS nodes '/>
13	<meta name='acknowledgement' content='Oahu image prepared by David Colleen and Planet 9 Inc.'/>
14	<meta name='reference' content='http://www.planet9.com'/>
15	<meta name='subject' content='NURBS Surface Example'/>
16	<meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Basic/NURBS/NurbsPatchSurfaceExampleWithOahuTexture.x3d'/>
17	<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
18	<meta name='license' content='../license.html'/>
19	</head>

20	<Scene>
21	<WorldInfo title='NurbsPatchSurfaceExampleWithOahuTexture.x3d'/>
22	<Viewpoint description='animatedPlane' position='3 2 40'/>
23	<Transform rotation='1 0 0 -1.5'>
24	<Shape>
25	<NurbsPatchSurface DEF='NS' solid='false' uDimension='5' uOrder='4' uTessellation='30' vDimension='5' vOrder='4' vTessellation='30' containerField='geometry'>
26	<!-- ROUTE information for NC node: [from CI.value_changed to set_point ] --> <Coordinate DEF='NC' containerField='controlPoint' point='-10 -10 0 -10 -5 0 -10 0 0 -10 5 0 -10 10 0 -5 -10 0 -5 -5 2.5 -5 0 5 -5 5 2.5 -5 10 0 0 -10 0 0 -5 2.5 0 0 5 0 5 2.5 0 10 0 5 -10 0 5 -5 2.5 5 0 15 5 5 2.5 5 10 0 10 -10 0 10 -5 0 10 0 0 10 5 0 10 10 0'/>
27	</NurbsPatchSurface>
28	<Appearance>
29	<ImageTexture url=' "PearlHarborLowResolution.jpg " "https://savage.nps.edu/Savage/Locations/Hawaii/PearlHarborLowResolution.jpg " '/>
30	</Appearance>
31	</Shape>
32	</Transform>
33	<!-- ROUTE information for TS node: [from fraction_changed to CI.set_fraction ] --> <TimeSensor DEF='TS' cycleInterval='6' loop='true'/>
34	<!-- ROUTE information for CI node: [from TS.fraction_changed to set_fraction ] [from value_changed to NC.set_point ] --> <CoordinateInterpolator DEF='CI' key='0 .5 1' keyValue='-10 -10 0 -10 -5 0 -10 0 0 -10 5 0 -10 10 0 -5 -10 0 -5 -5 2.5 -5 0 5 -5 5 2.5 -5 10 0 0 -10 0 0 -5 2.5 0 0 5 0 5 2.5 0 10 0 5 -10 0 5 -5 2.5 5 0 15 5 5 2.5 5 10 0 10 -10 0 10 -5 0 10 0 0 10 5 0 10 10 0 -10 -10 0 -10 -5 0 -10 0 0 -10 5 0 -10 10 0 -5 -10 0 -5 -5 0 -5 0 0 -5 5 0 -5 10 0 0 -10 0 0 -5 0 0 0 0 0 5 0 0 10 0 5 -10 0 5 -5 0 5 0 0 5 5 0 5 10 0 10 -10 0 10 -5 0 10 0 0 10 5 0 10 10 0 -10 -10 0 -10 -5 0 -10 0 0 -10 5 0 -10 10 0 -5 -10 0 -5 -5 2.5 -5 0 5 -5 5 2.5 -5 10 0 0 -10 0 0 -5 2.5 0 0 5 0 5 2.5 0 10 0 5 -10 0 5 -5 2.5 5 0 15 5 5 2.5 5 10 0 10 -10 0 10 -5 0 10 0 0 10 5 0 10 10 0'/>
35	< ROUTE fromNode='TS' fromField='fraction_changed' toNode='CI' toField='set_fraction'/>
36	< ROUTE fromNode='CI' fromField='value_changed' toNode='NC' toField='set_point'/>
37	</Scene>
38	</X3D>
