X3D Model Documentation: Chair.x3d

1	`<?xml version="1.0" encoding="UTF-8"?>`
2	`<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">`
3	<X3D profile='Immersive' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
4	<head>
5	<meta name='title' content='Chair.x3d'/>
6	<meta name='description' content='A chair for a room, modeled as a Prototype for reuse.'/>
7	<meta name='creator' content='Frederic Roussille'/>
8	<meta name='contributor' content='Don Brutzman'/>
9	<meta name='created' content='1 April 2001'/>
10	<meta name='modified' content='20 October 2019'/>
11	<meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Chair.x3d'/>
12	<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
13	<meta name='license' content='../license.html'/>
14	</head>

<!--

Event Graph ROUTE Table shows event connections.

-->

<!--

Index for DEF nodes: chair_color, chaise, color, ExtrusionSeatBack, ExtrusionSeatBase, ExtrusionSeatCushion, seat, SeatRotationCylinderSensor

Index for Viewpoint node: Viewpoint_1

Index for ProtoDeclare definition: Chair

-->

15	<Scene>
16	<WorldInfo title='Chair.x3d'/>
17	<Viewpoint description='Chair example ProtoInstance' position='0 0 4'/>
18	<ProtoDeclare name='Chair'>
19	<ProtoInterface>
20	<field name='diffuseColor' type='SFColor' value='0.7 0.7 0.4' accessType='inputOutput'/>
21	</ProtoInterface>
22	<ProtoBody>
23	<Transform scale='0.15 0.15 0.15' translation='0 0.52 0'>
24	<!-- ROUTE information for seat node: [from SeatRotationCylinderSensor.rotation_changed to set_rotation ] --> <Transform DEF='seat'>
25	<Transform rotation='1 0 0 1.57'>
26	<!-- seat -->
27	<Shape>
28	<!-- Appearance chair_color is a DEF node that has 2 USE nodes: USE_1, USE_2 --> <Appearance DEF='chair_color'>
29	<Material DEF='color'>
30	<IS>
31	<connect nodeField='diffuseColor' protoField='diffuseColor'/>
32	</IS>
33	</Material>
34	</Appearance>
35	<Extrusion DEF='ExtrusionSeatCushion' ccw='false' creaseAngle='1.57' crossSection='-2 0 2 0 2.3 0.3 2.4 0.4 2.5 0.5 2.5 1 -2 1 -2 0' scale='0.5 1' solid='false' spine='1 0 0 0.92 -0.38 0 0.71 -0.71 0 0.38 -0.92 0 0 -1 0 -0.38 -0.92 0 -0.71 -0.71 0 -0.92 -0.38 0 -1 0 0 -0.92 0.38 0 -0.71 0.71 0 -0.38 0.92 0 0 1 0 0.38 0.92 0 0.71 0.71 0 0.92 0.38 0 1 0 0'/>
36	</Shape>
37	</Transform>
38	<Transform translation='0 1 1'>
39	<!-- back -->
40	<Shape>
41	<Appearance USE='chair_color'/>
42	<Extrusion DEF='ExtrusionSeatBack' convex='false' creaseAngle='1.57' crossSection='1 0 0.8 0 0.736 0.304 0.568 0.568 0.304 0.736 0 0.8 -0.304 0.736 -0.568 0.568 -0.736 0.304 -0.8 0 -1 0 -0.92 0.38 -0.71 0.71 -0.38 0.92 0 1 0.38 0.92 0.71 0.71 0.92 0.38 1 0 0.8 0' scale='1.4 1 2 1' solid='false' spine='0 0 0 0 4 0'/>
43	</Shape>
44	</Transform>
45	<!-- ROUTE information for SeatRotationCylinderSensor node: [from rotation_changed to seat.set_rotation ] --> <CylinderSensor DEF='SeatRotationCylinderSensor' description='Swivel chair'/>
46	</Transform>
47	<Transform rotation='1 0 0 -1.57'>
48	<!-- foot -->
49	<Shape>
50	<Appearance USE='chair_color'/>
51	<Extrusion DEF='ExtrusionSeatBase' beginCap='false' convex='false' creaseAngle='1.57' crossSection='0 0 0.2 0 0.23 2 0.28 3 1 3.3 1.5 3.5 0 3.5 0 0' endCap='false' solid='false' spine='0.1 0 0 0.092 -0.038 0 0.071 -0.071 0 0.038 -0.092 0 0 -0.1 0 -0.038 -0.092 0 -0.071 -0.071 0 -0.092 -0.038 0 -0.1 0 0 -0.092 0.038 0 -0.071 0.071 0 -0.038 0.092 0 0 0.1 0 0.038 0.092 0 0.071 0.071 0 0.092 0.038 0 0.1 0 0'/>
52	</Shape>
53	</Transform>
54	</Transform>
55	< ROUTE fromNode='SeatRotationCylinderSensor' fromField='rotation_changed' toNode='seat' toField='set_rotation'/>
56	</ProtoBody>
57	</ProtoDeclare>
58	<ProtoInstance name='Chair' DEF='chaise'/>
59	</Scene>
60	</X3D>

<!--

Event Graph ROUTE Table shows event connections.

-->

<!--

Index for DEF nodes: chair_color, chaise, color, ExtrusionSeatBack, ExtrusionSeatBase, ExtrusionSeatCushion, seat, SeatRotationCylinderSensor

Index for Viewpoint node: Viewpoint_1

Index for ProtoDeclare definition: Chair

-->

X3D Tooltips element index: Appearance, connect, CylinderSensor, Extrusion, field, head, IS, Material, meta, ProtoBody, ProtoDeclare, ProtoInstance, ProtoInterface, ROUTE, Scene, Shape, Transform, Viewpoint, WorldInfo, X3D, accessType and type, XML data types, field types

Event Graph ROUTE Table with 1 ROUTE connection total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

chaise
ProtoInstance
Chair

No ROUTE connection found for output events from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

SeatRotationCylinderSensor
CylinderSensor
rotation_changed
SFRotation

→
ROUTE
event to
(1)

seat
Transform
set_rotation
SFRotation

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀

-->
