X3D Model Documentation: Example08.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
  3  <X3D profile='Interactive' version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
  4       <head>
  5            <meta name='title' content='Example08.x3d'/>
  6            <meta name='creator' content='Don Brutzman'/>
  7            <meta name='created' content='27 June 2000'/>
  8            <meta name='modified' content='28 October 2019'/>
  9            <meta name='creator' content='X3D working group'/>
 10            <meta name='reference' content='originals/exampleD_8.wrl'/>
 11            <meta name='description' content='VRML 97 specification example: Anchor examples.'/>
 12            <meta name='specificationSection' content='VRML 97, ISO/IEC 14772-1, Part 1: Functional specification and UTF-8 encoding, D.8 Anchor'/>
 13            <meta name='specificationUrl' content='https://www.web3d.org/documents/specifications/14772/V2.0/part1/examples.html#D.8'/>
 14            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Basic/Vrml97Specification/Example08.x3d'/>
 15            <meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
 16            <meta name='license' content='../license.html'/>
 17       </head>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->

<!-- to top Index for DEF nodes: DefaultAppearance, Doorway

Index for Viewpoint node: Doorway
-->
 18       <Scene>
 19            <WorldInfo title='Example08.x3d'/>
 20            <Anchor description='example link' parameter='"target=name_of_frame"'   url=' "http://somehost/somefile.html" '>
 21                 <Shape>
 22                      <Cylinder/>
 23
                    <!-- Appearance DefaultAppearance is a DEF node that has 1 USE node: USE_1 -->
                     <Appearance DEF='DefaultAppearance'>
 24                           <Material/>
 25                      </Appearance>
 26                 </Shape>
 27            </Anchor>
 28            <Anchor description='another example link'   url=' "http://www.school.edu/vrml/someScene.wrl#OverView" '>
 29                 <Shape>
 30                      <Box/>
 31                      <Appearance USE='DefaultAppearance'/>
 32                 </Shape>
 33            </Anchor>
 34            <!-- Doorway Viewpoint added. -->
 35            <Viewpoint DEF='Doorway' description='Example view'/>
 36            <!-- Error in the VRML 97 specification example: the following Anchor url did not point to a Viewpoint. Doorway Viewpoint needed. -->
 37            <Anchor description='Doorway viewpoint'   url=' "#Doorway" '>
 38                 <Shape>
 39                      <Sphere/>
 40                 </Shape>
 41            </Anchor>
 42       </Scene>
 43  </X3D>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->

<!-- to top Index for DEF nodes: DefaultAppearance, Doorway

Index for Viewpoint node: Doorway
-->
X3D Tooltips element index: Anchor, Appearance, Box, Cylinder, head, Material, meta, Scene, Shape, Sphere, Viewpoint, WorldInfo, X3D, accessType and type, XML data types, field types

Event Graph ROUTE Table with 0 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.
