X3D Model Documentation: Figure04_11TextOverstrikeFont.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
  3  <X3D profile='Immersive' version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
  4       <head>
  5            <meta name='title' content='Figure04_11TextOverstrikeFont.x3d'/>
  6            <meta name='creator' content='Figure 4.11, The VRML 2.0 Sourcebook, Copyright [1997] By Andrea L. Ames, David R. Nadeau, and John L. Moreland'/>
  7            <meta name='reference' content='http://www.wiley.com/legacy/compbooks/vrml2sbk/ch04/04fig11.htm'/>
  8            <meta name='translator' content='Don Brutzman'/>
  9            <meta name='created' content='6 August 2000'/>
 10            <meta name='modified' content='20 October 2019'/>
 11            <meta name='description' content='Show overstrike, using DEF and USE to share font properties.'/>
 12            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Chapter04Text/Figure04_11TextOverstrikeFont.x3d'/>
 13            <meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
 14            <meta name='license' content='../../license.html'/>
 15       </head>
<!--
<!-- -->

<!-- to top Index for DEF nodes: MY_FONTSTYLE, WHITE_SPECULAR

Index for Viewpoint nodes: Viewpoint_1, Viewpoint_2
-->
 16       <Scene>
 17            <WorldInfo title='Figure04_11TextOverstrikeFont.x3d'/>
 18            <Viewpoint description='View from 30m away' position='0 0 30'/>
 19            <Viewpoint description='Default viewpoint at (0 0 10) is way too close!! That is a bad place to be, provide a replacement viewpoint instead.'/>
 20            <Shape>
 21
               <!-- Appearance WHITE_SPECULAR is a DEF node that has 1 USE node: USE_1 -->
                <Appearance DEF='WHITE_SPECULAR'>
 22                      <Material specularColor='1 1 1'/>
 23                 </Appearance>
 24                 <Text string='"Over" "Strike"'>
 25
                    <!-- FontStyle MY_FONTSTYLE is a DEF node that has 1 USE node: USE_1 -->
                     <FontStyle DEF='MY_FONTSTYLE' family='"TYPEWRITER"' justify='"MIDDLE" "MIDDLE"' size='6'/>
 26                 </Text>
 27            </Shape>
 28            <Shape>
 29                 <Appearance USE='WHITE_SPECULAR'/>
 30                 <Text string='"----" "------"'>
 31                      <FontStyle USE='MY_FONTSTYLE'/>
 32                 </Text>
 33            </Shape>
 34       </Scene>
 35  </X3D>
<!--
<!-- -->
