<?xml version="1.0" encoding="UTF-8"?>
|
| 2 |
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
|
| 3 | <X3D profile='Immersive' version='3.3' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.3.xsd'> |
| 4 | <head> |
| 5 | <meta name='title' content='CutPlane.x3d'/> |
| 6 | <meta name='description' content='Cutting plane demo where users can drag two slice interfaces to show the cross sections of a volume.'/> |
| 7 | <meta name='creator' content='David R. Nadeau'/> |
| 8 | <meta name='translator' content='Don Brutzman'/> |
| 9 | <meta name='created' content='1 July 1998'/> |
| 10 | <meta name='translated' content='2 February 2014'/> |
| 11 | <meta name='modified' content='20 October 2019'/> |
| 12 |
<meta name='Image' content='CutPlane.png'/>
|
| 13 | <meta name='reference' content='originals/cutplane.wrl'/> |
| 14 | <meta name='reference' content='http://www.siggraph.org/s98'/> |
| 15 | <meta name='reference' content='http://www.siggraph.org/s98/conference/courses/18.html'/> |
| 16 | <meta name='reference' content='http://www.sdsc.edu/~moreland/courses/Siggraph98/vrml97/slides/mt0008.htm'/> |
| 17 | <meta name='reference' content='http://www.sdsc.edu/~moreland/courses/Siggraph98/vrml97/slides/mt0498.htm'/> |
| 18 | <meta name='reference' content='http://www.sdsc.edu/~moreland/courses/Siggraph98/vrml97/vrml97.htm'/> |
| 19 | <meta name='reference' content='https://www.web3d.org/x3d/content/examples/X3dResources.html'/> |
| 20 | <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/CutPlane.x3d'/> |
| 21 | <meta name='generator' content='Vrml97ToX3dNist, http://ovrt.nist.gov/v2_x3d.html'/> |
| 22 | <meta name='generator' content='X3D-Edit, https://savage.nps.edu/X3D-Edit'/> |
| 23 | <meta name='license' content='../license.html'/> |
| 24 | </head> |
Index for DEF node:
| 25 | <Scene> |
| 26 | <!-- This sliding cutting plane world illustrates the use of the 'SlidingPlane' prototype node defined in the external file 'cut.wrl'. That node creates a plane that slides back and forth, changing the texture on it based upon the plane's X position. --> |
| 27 | <ExternProtoDeclare name='TexturePlane' url=' "Cut.x3d#TexturePlane" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/Cut.x3d#TexturePlane" "Cut.wrl#TexturePlane" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/Cut.wrl#TexturePlane" '> |
| 28 | <field name='textures' type='MFNode' accessType='initializeOnly'/> |
| 29 | <field name='set_fraction' type='SFFloat' accessType='inputOnly'/> |
| 30 | </ExternProtoDeclare> |
| 31 | <ExternProtoDeclare name='SlidingPlane' url=' "Cut.x3d#SlidingPlane" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/Cut.x3d#SlidingPlane" "Cut.wrl#SlidingPlane" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/Cut.wrl#SlidingPlane" '> |
| 32 | <field name='textures' type='MFNode' accessType='initializeOnly'/> |
| 33 | <field name='minMaxX' type='SFVec2f' accessType='initializeOnly'/> |
| 34 | <field name='initialX' type='SFFloat' accessType='initializeOnly'/> |
| 35 | </ExternProtoDeclare> |
| 36 | <WorldInfo info='"Copyright (c) 1997, David R. Nadeau"' title='Cutting Plane'/> |
| 37 | <Viewpoint description='Entry view' orientation='0.0 1.0 0.0 0.785' position='4.0 0.4 2.5'/> |
| 38 | <NavigationInfo/> |
| 39 | <Background skyAngle='1.57 1.87' skyColor='0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.1 0.3'/> |
| 40 | <Shape> |
| 41 | <Appearance> |
| 42 | <TextureTransform translation='0.5 0.5'/> |
| 43 |
<ImageTexture
url=' "grill.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/grill.png
" '/>
|
| 44 | </Appearance> |
| 45 | <IndexedFaceSet solid='false' coordIndex='0 1 2 3 -1 4 5 6 7 -1 8 9 10 11 -1' texCoordIndex='0 1 2 3 -1 1 2 3 0 -1 4 5 6 7 -1'> |
| 46 | <TextureCoordinate point='0.0 0.0 0.0 8.0 4.0 8.0 4.0 0.0 0.0 0.0 4.0 0.0 4.0 4.0 0.0 4.0'/> |
| 47 | <Coordinate point='-1.0 -1.0 0.0 -1.0 -1.0 -4.0 -1.0 1.0 -4.0 -1.0 1.0 0.0 -1.0 -1.0 0.0 1.0 -1.0 0.0 1.0 -1.0 -4.0 -1.0 -1.0 -4.0 -1.0 -1.0 -4.0 1.0 -1.0 -4.0 1.0 1.0 -4.0 -1.0 1.0 -4.0'/> |
| 48 | </IndexedFaceSet> |
| 49 | </Shape> |
| 50 | <Transform rotation='0.0 1.0 0.0 1.571' translation='-1.0 1.3 -2.0'> |
| 51 | <Shape> |
| 52 | <Appearance/> |
| 53 | <Text string='"Time (sec)"'> |
| 54 | <FontStyle justify='"MIDDLE" "MIDDLE"' size='0.4' style='BOLD'/> |
| 55 | </Text> |
| 56 | </Shape> |
| 57 | </Transform> |
| 58 | <!-- Create two moving cutting planes, one initially at the front and the other initially at the back. --> |
| 59 | <ProtoInstance name='SlidingPlane'> |
| 60 | <fieldValue name='textures'> |
| 61 |
<ImageTexture
url=' "cp1.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp1.png
" '/>
|
| 62 |
<ImageTexture
url=' "cp2.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp2.png
" '/>
|
| 63 |
<ImageTexture
url=' "cp3.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp3.png
" '/>
|
| 64 |
<ImageTexture
url=' "cp4.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp4.png
" '/>
|
| 65 |
<ImageTexture
url=' "cp5.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp5.png
" '/>
|
| 66 |
<ImageTexture
url=' "cp6.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp6.png
" '/>
|
| 67 |
<ImageTexture
url=' "cp7.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp7.png
" '/>
|
| 68 |
<ImageTexture
url=' "cp8.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp8.png
" '/>
|
| 69 |
<ImageTexture
url=' "cp9.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp9.png
" '/>
|
| 70 |
<ImageTexture
url=' "cp10.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp10.png
" '/>
|
| 71 | </fieldValue> |
| 72 | <fieldValue name='minMaxX' value='0.0 4.0'/> |
| 73 | <fieldValue name='initialX' value='0.0'/> |
| 74 | </ProtoInstance> |
| 75 | <ProtoInstance name='SlidingPlane'> |
| 76 | <fieldValue name='textures'> |
| 77 |
<ImageTexture
url=' "cp1.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp1.png
" '/>
|
| 78 |
<ImageTexture
url=' "cp2.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp2.png
" '/>
|
| 79 |
<ImageTexture
url=' "cp3.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp3.png
" '/>
|
| 80 |
<ImageTexture
url=' "cp4.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp4.png
" '/>
|
| 81 |
<ImageTexture
url=' "cp5.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp5.png
" '/>
|
| 82 |
<ImageTexture
url=' "cp6.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp6.png
" '/>
|
| 83 |
<ImageTexture
url=' "cp7.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp7.png
" '/>
|
| 84 |
<ImageTexture
url=' "cp8.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp8.png
" '/>
|
| 85 |
<ImageTexture
url=' "cp9.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp9.png
" '/>
|
| 86 |
<ImageTexture
url=' "cp10.png
" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp10.png
" '/>
|
| 87 | </fieldValue> |
| 88 | <fieldValue name='minMaxX' value='0.0 4.0'/> |
| 89 | <fieldValue name='initialX' value='3.6'/> |
| 90 | </ProtoInstance> |
| 91 | </Scene> |
| 92 | </X3D> |
