X3D Model Documentation: Match.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
  3  <X3D profile='Immersive' version='3.3'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.3.xsd'>
  4       <head>
  5            <meta name='title' content='Match.x3d'/>
  6            <meta name='description' content='A Match! This world illustrates the use of the externally defined Flames prototype, which creates an animated flame to show the head of a burning match.'/>
  7            <meta name='creator' content='David R. Nadeau'/>
  8            <meta name='translator' content='Don Brutzman'/>
  9            <meta name='created' content='1 July 1998'/>
 10            <meta name='translated' content='2 February 2014'/>
 11            <meta name='modified' content='20 October 2019'/>
 12            <meta name='Image' content='Match.png'/>
 13            <meta name='reference' content='originals/match.wrl'/>
 14            <meta name='reference' content='http://www.siggraph.org/s98'/>
 15            <meta name='reference' content='http://www.siggraph.org/s98/conference/courses/18.html'/>
 16            <meta name='reference' content='http://www.sdsc.edu/~moreland/courses/Siggraph98/vrml97/slides/mt0499.htm'/>
 17            <meta name='reference' content='http://www.sdsc.edu/~moreland/courses/Siggraph98/vrml97/vrml97.htm'/>
 18            <meta name='reference' content='https://www.web3d.org/x3d/content/examples/X3dResources.html'/>
 19            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/Match.x3d'/>
 20            <meta name='generator' content='Vrml97ToX3dNist, http://ovrt.nist.gov/v2_x3d.html'/>
 21            <meta name='generator' content='X3D-Edit, https://savage.nps.edu/X3D-Edit'/>
 22            <meta name='license' content='../license.html'/>
 23       </head>
<!--
<!-- to top Index for DEF node:

Index for Viewpoint node: Viewpoint_1

Index for ExternProtoDeclare definition: Flames
-->
 24       <Scene>
 25            <WorldInfo info='"Copyright (c) 1997, David R. Nadeau"' title='A Match!'/>
 26            <Viewpoint description='Entry view' position='0.0 0.3 4.0'/>
 27            <NavigationInfo/>
 28            <Background skyAngle='1.57 1.87' skyColor='0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.2 0.0'/>
 29            <ExternProtoDeclare name='Flames'   url=' "Flames.x3d#Flames" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/Flames.x3d#Flames" "Flames.wrl#Flames" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/Flames.wrl#Flames" '>
 30                 <field name='startTime' type='SFTime' accessType='initializeOnly'/>
 31                 <field name='cycleInterval' type='SFTime' accessType='initializeOnly'/>
 32            </ExternProtoDeclare>
 33            <Billboard>
 34                 <ProtoInstance name='Flames'/>
 35            </Billboard>
 36            <Transform translation='0.0 -0.2 0.0'>
 37                 <Transform scale='0.5 1.0 0.5'>
 38                      <Shape>
 39                           <Appearance>
 40                                <Material diffuseColor='0.3 0.3 0.3'/>
 41                           </Appearance>
 42                           <Sphere radius='0.3'/>
 43                      </Shape>
 44                 </Transform>
 45                 <Transform translation='0.0 -1.2 0.0'>
 46                      <Shape>
 47                           <Appearance>
 48                                <Material diffuseColor='0.8 0.7 0.5'/>
 49                           </Appearance>
 50                           <Box size='0.1 2.0 0.1'/>
 51                      </Shape>
 52                 </Transform>
 53            </Transform>
 54       </Scene>
 55  </X3D>
<!--
