X3D Model Documentation: TexturePlane.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
  3  <X3D profile='Immersive' version='3.3'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.3.xsd'>
  4       <head>
  5            <meta name='title' content='TexturePlane.x3d'/>
  6            <meta name='description' content='Animating textured plane: this world illustrates the use of the TexturePlane prototype node defined in an external file. That node creates a textured square whose texture changes based upon an input fraction. This world animates that fraction to cause the texture to animate.'/>
  7            <meta name='creator' content='David R. Nadeau'/>
  8            <meta name='translator' content='Don Brutzman'/>
  9            <meta name='created' content='1 July 1998'/>
 10            <meta name='translated' content='2 February 2014'/>
 11            <meta name='modified' content='20 October 2019'/>
 12            <meta name='Image' content='TexturePlane.png'/>
 13            <meta name='reference' content='originals/texplane.wrl'/>
 14            <meta name='reference' content='http://www.siggraph.org/s98'/>
 15            <meta name='reference' content='http://www.siggraph.org/s98/conference/courses/18.html'/>
 16            <meta name='reference' content='http://www.sdsc.edu/~moreland/courses/Siggraph98/vrml97/slides/mt0497.htm'/>
 17            <meta name='reference' content='http://www.sdsc.edu/~moreland/courses/Siggraph98/vrml97/vrml97.htm'/>
 18            <meta name='reference' content='https://www.web3d.org/x3d/content/examples/X3dResources.html'/>
 19            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/TexturePlane.x3d'/>
 20            <meta name='generator' content='Vrml97ToX3dNist, http://ovrt.nist.gov/v2_x3d.html'/>
 21            <meta name='generator' content='X3D-Edit, https://savage.nps.edu/X3D-Edit'/>
 22            <meta name='license' content='../license.html'/>
 23       </head>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->

<!-- to top Index for DEF nodes: Clock, Plane

Index for Viewpoint node: Viewpoint_1

Index for ExternProtoDeclare definition: TexturePlane
-->
 24       <Scene>
 25            <ExternProtoDeclare name='TexturePlane'   url=' "Cut.x3d#TexturePlane" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/Cut.x3d#TexturePlane" "Cut.wrl#TexturePlane" "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/Cut.wrl#TexturePlane" '>
 26                 <field name='textures' type='MFNode' accessType='initializeOnly'/>
 27                 <field name='set_fraction' type='SFFloat' accessType='inputOnly'/>
 28            </ExternProtoDeclare>
 29            <WorldInfo info='"Copyright (c) 1997, David R. Nadeau"' title='Animating textured plane'/>
 30            <Viewpoint description='Entry view' position='0.0 0.0 3.0'/>
 31            <NavigationInfo/>
 32            <Background skyAngle='1.57 1.87' skyColor='0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.1 0.3'/>
 33            <Shape>
 34                 <Appearance>
 35                      <TextureTransform translation='0.5 0.5'/>
 36                      <ImageTexture   url=' "grill.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/grill.png " '/>
 37                 </Appearance>
 38                 <IndexedFaceSet solid='false' coordIndex='0 1 2 3 -1' texCoordIndex='0 1 2 3 -1'>
 39                      <TextureCoordinate point='0.0 0.0 4.0 0.0 4.0 4.0 0.0 4.0'/>
 40                      <Coordinate point='-1.0 -1.0 -0.05 1.0 -1.0 -0.05 1.0 1.0 -0.05 -1.0 1.0 -0.05'/>
 41                 </IndexedFaceSet>
 42            </Shape>
 43
          <!-- ROUTE information for Plane node:  [from Clock.fraction_changed to set_fraction ] -->
           <ProtoInstance name='TexturePlane' DEF='Plane'>
 44                 <fieldValue name='textures'>
 45                      <ImageTexture   url=' "cp1.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp1.png " '/>
 46                      <ImageTexture   url=' "cp2.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp2.png " '/>
 47                      <ImageTexture   url=' "cp3.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp3.png " '/>
 48                      <ImageTexture   url=' "cp4.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp4.png " '/>
 49                      <ImageTexture   url=' "cp5.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp5.png " '/>
 50                      <ImageTexture   url=' "cp6.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp6.png " '/>
 51                      <ImageTexture   url=' "cp7.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp7.png " '/>
 52                      <ImageTexture   url=' "cp8.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp8.png " '/>
 53                      <ImageTexture   url=' "cp9.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp9.png " '/>
 54                      <ImageTexture   url=' "cp10.png " "https://www.web3d.org/x3d/content/examples/Vrml2Sourcebook/Siggraph98Course/cp10.png " '/>
 55                 </fieldValue>
 56            </ProtoInstance>
 57
          <!-- ROUTE information for Clock node:  [from fraction_changed to Plane.set_fraction ] -->
           <TimeSensor DEF='Clock' cycleInterval='3.0' loop='true' startTime='1.0'/>
 58            < ROUTE  fromNode='Clock' fromField='fraction_changed' toNode='Plane' toField='set_fraction'/>
 59       </Scene>
 60  </X3D>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->

<!-- to top Index for DEF nodes: Clock, Plane

Index for Viewpoint node: Viewpoint_1

Index for ExternProtoDeclare definition: TexturePlane
-->
X3D Tooltips element index: Appearance, Background, Coordinate, ExternProtoDeclare, field, fieldValue, head, ImageTexture, IndexedFaceSet, meta, NavigationInfo, ProtoInstance, ROUTE, Scene, Shape, TextureCoordinate, TextureTransform, TimeSensor, Viewpoint, WorldInfo, X3D, accessType and type, XML data types, field types

Event Graph ROUTE Table with 1 ROUTE connection total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

Clock
TimeSensor
fraction_changed
SFFloat
→
ROUTE
event to
(1)
Plane
ProtoInstance
set_fraction
SFFloat

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀
-->
