Bouncing Box using Simulink

The Matlab toolkit from Mathworks includes numerous mathematical and scientific packages. Simulink can be used for animation visualization using VRML models, which are easily created from X3D. X3D models can be converted to VRML for use with Simulink and other Matlab tools.

Support is available for X3D and VRML. X3D models can be converted to VRML for use with Simulink and other Matlab tools.

Web3D 2015 conference resources: Simulink demo, poster paper, Fast Forward slides (.pdf) and video.

2 X3D Models                 8 X3D Model Viewpoint Snapshots

BouncingBoxSimulink
Bouncing Box Simulink.x3d
[1] BouncingBoxSimulink.x3d Hello Matlab Simulink bouncing box!
[2] BouncingBoxSimulink.x3d Closeup view Simulink bouncing box!
[3] BouncingBoxSimulink.x3d (default X3D view from 0 0 10)

PhasedArrayBeamExample
Phased Array Beam Example.x3d
[4] PhasedArrayBeamExample.x3d Oblique view
[5] PhasedArrayBeamExample.x3d View along Z axis
[6] PhasedArrayBeamExample.x3d View along X axis
[7] PhasedArrayBeamExample.x3d View along Y axis
[8] PhasedArrayBeamExample.x3d (default X3D view from 0 0 10)
