X3D Model Documentation: HelloX3dAuthors.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
  3  <X3D profile='Immersive' version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
  4       <head>
  5            <meta name='title' content='HelloX3dAuthors.x3d'/>
  6            <meta name='creator' content='Don Brutzman'/>
  7            <meta name='created' content='5 October 2000'/>
  8            <meta name='modified' content='20 October 2019'/>
  9            <meta name='description' content='Simple example showing spinning globe and text. Hello!'/>
 10            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/Basic/course/HelloX3dAuthors.x3d'/>
 11            <meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
 12            <meta name='license' content='../license.html'/>
 13       </head>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->

<!-- to top Index for DEF nodes: EarthCoordinateSystem, MiniWorld, OrbitalTimeInterval, SimpleGeoStationarySatellite, SpinThoseThings

Index for Viewpoint node: Viewpoint_1
-->
 14       <Scene>
 15            <WorldInfo info='"an introductory scene"' title='Hello X3D Authors'/>
 16            <Viewpoint description='Hello, world' orientation='0 1 0 3.14159' position='0 0 -8'/>
 17
          <!-- ROUTE information for OrbitalTimeInterval node:  [from fraction_changed to SpinThoseThings.set_fraction ] -->
           <TimeSensor DEF='OrbitalTimeInterval' cycleInterval='12.0' loop='true'/>
 18
          <!-- ROUTE information for SpinThoseThings node:  [from OrbitalTimeInterval.fraction_changed to set_fraction ] [from value_changed to EarthCoordinateSystem.rotation ] -->
           <OrientationInterpolator DEF='SpinThoseThings' key='0.00 0.25 0.50 0.75 1.00' keyValue='0 1 0 0 0 1 0 1.57079 0 1 0 3.14159 0 1 0 4.7123889 0 1 0 6.2831852'/>
 19            < ROUTE  fromNode='OrbitalTimeInterval' fromField='fraction_changed' toNode='SpinThoseThings' toField='set_fraction'/>
 20
          <!-- ROUTE information for EarthCoordinateSystem node:  [from SpinThoseThings.value_changed to rotation ] -->
           <Transform DEF='EarthCoordinateSystem'>
 21                 <Group DEF='MiniWorld'>
 22                      <Shape>
 23                           <Appearance>
 24                                <ImageTexture   url=' "earth-topo.png " "earth-topo.gif " "earth-topo-small.gif " "https://www.web3d.org/x3d/content/examples/Basic/course/earth-topo.png " "https://www.web3d.org/x3d/content/examples/Basic/course/earth-topo.gif " '/>
 25                           </Appearance>
 26                           <Sphere/>
 27                      </Shape>
 28                 </Group>
 29                 <Transform DEF='SimpleGeoStationarySatellite' rotation='1 0 0 .3' scale='0.1 0.3 0.1' translation='0 0 5'>
 30                      <Shape>
 31                           <Appearance>
 32                                <Material diffuseColor='0.9 0.1 0.1'/>
 33                           </Appearance>
 34                           <Text string='"Hello X3D Authors !!"'>
 35                                <FontStyle size='3'/>
 36                           </Text>
 37                      </Shape>
 38                 </Transform>
 39            </Transform>
 40            < ROUTE  fromNode='SpinThoseThings' fromField='value_changed' toNode='EarthCoordinateSystem' toField='rotation'/>
 41       </Scene>
 42  </X3D>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->

<!-- to top Index for DEF nodes: EarthCoordinateSystem, MiniWorld, OrbitalTimeInterval, SimpleGeoStationarySatellite, SpinThoseThings

Index for Viewpoint node: Viewpoint_1
-->
X3D Tooltips element index: Appearance, FontStyle, Group, head, ImageTexture, Material, meta, OrientationInterpolator, ROUTE, Scene, Shape, Sphere, Text, TimeSensor, Transform, Viewpoint, WorldInfo, X3D, accessType and type, XML data types, field types

Event Graph ROUTE Table with 2 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

OrbitalTimeInterval
TimeSensor
fraction_changed
SFFloat
→
ROUTE
event to
(1)
SpinThoseThings
OrientationInterpolator
set_fraction
SFFloat 		then


  		SpinThoseThings
OrientationInterpolator
value_changed
SFRotation
→
ROUTE
event to
(2)
EarthCoordinateSystem
Transform
rotation
SFRotation
Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀
-->
